T-H Marine Atlas Hyd Jack Plate 4" Black

T-H Marine CMC Atlas Series Hydraulic Jack Plates - Black: 4", 6", 8", 10", and 12"

Designed to meet even the most challenging demands of today’s high-performance outboards, the T-H Marine Atlas Hydraulic Jack Plate is right for the job. Featuring a one-piece design with a powerful, innovative rod and a slot lifting system that can handle even the heaviest V6 outboards up to 300hp. All hydraulics are built into the jack, relieving you of having to install those annoying pumps and reservoirs inside the transom. Even better, the hydraulic unit is lighting-fast, able to lift from the bottom to the top in just 8 seconds.

The T-H Marine Hydraulic Jack Plate is designed to hold heavy-duty loads, even four-stroke engines. The high tech, engineered polymer rod, and slot lifting design guarantees trouble-free action! Finally, you can have it all - an installation-free, one-piece hydraulic pump that pumps in only 8 seconds and best of all - can handle V6 engines up to 300hp.

Features:

Self Contained hydraulics Fast 8 second lift time

Rod and slot lifting design, high tech polymer rods

Easy to install - easy to service

Installs in half the time of comparable jacks

Available in 4'' , 6'' , 8'' , 10'', and 12" Setback models

Lifetime warranty on frame & 3 years on hydraulics

Includes Relay Pack and Switch

Why Buy ATLAS Hydraulic Jack Plate

- ATLAS™ is truly the best hydraulic jack plate in the world - ATLAS™ is factory installed by more boat manufacturers than any other plate - ATLAS™ is used by more Professional fisherman than any other hydraulic jack plate - ATLAS™ is the #1 selling hydraulic plate in the world / sold & serviced by more outlets- ATLAS™ hydraulic actuator is made in the U.S.A., our competition's is from China

How ATLAS Changed Hydraulic Jack Plates

- ATLAS is made by T-H Marine/CMC, who were the FIRST to offer an actuator inside the jack plate - the competition copied- ATLAS is first plate to offer predrilling for shallow water anchors - the competition copied- ATLAS is first and still only plate that does not require regular grease lubrication - the competing design cannot do that- ATLAS is first plate to include a heavy duty safety cable to protect boaters from engine entering cockpit upon failure- ATLAS is first plate to offer very simple actuator replacement in the field- ATLAS was first major development in hydraulic jack plates in over a decade - spurring hydraulic jack plate improvement

T-H Marine Atlas Jack Plate Installation Instructions

Contents:

Atlas Hydraulic Jack Plate

Wire harness and accessories

Installation instructions and warranty card

Instructions:

• If no outboard engine is mounted to transom, skip to jack plate mounting instructions.
• If outboard motor is mounted to transom:

Remove engine using proper lifting equipment and procedures.

Remove mounting bolts and nuts then carefully swing motor away from boat. It should not be necessary to remove any cables or wires as most installations have adequate length.

Disconnect any wires or cables that do not have necessary length and obtain longer wires or cables for completion of installation.

Mounting your Atlas Jack Plate:

Prepare transom for mounting by removing any silicone residue, dirt or oil.

Put a fresh and generous bead of silicone around each mounting hole.

Mount the Atlas jack plate to transom (shortest side 2 ½” long) using the bolts and nuts from engine removal.

Note: If you do not have engine mounting bolts, you will need ½” stainless mounting molts and appropriate washers and lock nuts to fit the thickness of your transom.

It is necessary in the installation that the bolts go through the transom then through the Atlas jack plate. The nuts attach to the bolts inside the jack plate.

When mounting the Atlas jack plate to your transom, you will note that there are three sets o…
