Rule Non-Automatic 12 Volt Bilge Pump With 1-1/8'' Discharge

Rule Non-Automatic 12 Volt Bilge Pump With 1-1/8'' Discharge

The Rule Non-Automatic 12 Volt Bilge Pump With 1-1/8'' Discharge features a high pumping capacity and reliability at a lower cost. Containing more exclusive design features than any comparable competitive pump. The bilge pumps are usually operated via a float switch or another level-sensing device with outputs between 1500 GPH to 4000 GPH. The Rule-10 2000 GPH is a high capacity submersible bilge pump that is typically installed with a three way switch to offer both automatic and manual override capabilities.

This pump is completely submersible and has a tough plastic body. Hidden air vents within the body help prevent air locking in challenging plumbing situations and helps with the check valve. The threaded discharge provides easier installation and easier maintenance, while e the snap-lock strainer base allows for easier cleaning. This pump also features a built in thermal cut-off which provides added protection to the pump and vessel.

Features:

Ignition protected

Long-life motor

Completely submersible

Rust and corrosion protected

Silent operation

Stainless steel shafts

Easy-clean

Marine-grade blocked wiring

Thermal cut-off

Threaded discharge

No burn-out when dry

RUL-02 1500 GPH Specs:

Capacity: 1500 GPH

Volts: 12 DC

Amp draw @ 12 V: 4 amp

Amp draw @ 13.6 V: 4.8 amp

Fuse Size: 10 (Amp)

Height: 6"

Width: 4.25"

Port type: 1-1/8" hose barb

Replacement strainer: Model 278

Panel switches: 41, 43, 45, 49

Float switches: 35A, 37A, 40A

RUL-10 2000 GPH Specs:

Capacity: 2000 GPH

Volts: 12 DC

Fuse size: 15

Amps @ 12 V: 7.3

Amps @ 13.6 V: 8.6

Height: 6"

Width: 4.25"

Replacement strainer: Model 278

Panel Switches: 41, 43, 45, 49

Float Switches: 35A, 37A, 40A

Click here for Rule Non-Automatic 12 Volt Bilge Pump With 1-1/8'' Discharge Installation Instructions

Frequently Asked Questions

• What is the Rule Non-Automatic 12 Volt Bilge Pump with 1-1/8" discharge designed for? This Rule bilge pump is designed for high-capacity bilge water removal in 12-volt marine applications. It is a non-automatic pump that is commonly paired with a float switch or other level-sensing device for automatic operation when needed.
• What pump sizes are available in this series? This series includes a 1500 GPH model and a 2000 GPH model. The 1500 GPH version is listed as RUL-02, while the 2000 GPH version is listed as RUL-10.
• What features help make this bilge pump durable and reliable? This pump is completely submersible and features a tough plastic body, stainless steel shaft, marine-grade blocked wiring, threaded discharge, snap-lock strainer base, and built-in thermal cut-off protection. Hidden air vents also help prevent air locking in difficult plumbing situations.
• Can this bilge pump be used with a float switch? Yes. This non-automatic bilge pump is typically used with a float switch or other level-sensing device. The listed compatible float switches include models 35A, 37A, and 40A.
• What discharge size does this bilge pump use? This Rule bilge pump uses a 1-1/8" discharge. The 1500 GPH model specifically lists a 1-1/8" hose barb port type.
