Blue Seas Fuse Block

Blue Sea Terminal Fuse Block 30 to 300A

The Blue Sea MRBF Terminal Fuse Block is compact and high-amp, appropriate for DC main, inverter, windlass and bow thruster circuit protection. This fuse block is provides high current protection in tight space constraints.

Features:

Isolated stud design uses standard M8 hardware and permits stacking of terminals

Insulating cap prevents accidental shorts

Accepts 5/16" ring terminals

Mounts on 3/8" terminal studs

Specifications:

Maximum Amperage: 300A

Maximum Voltage: 58V DC

Maximum Torque: 75 in-lb

Terminal Stud: M8

Weight: 0.16lb

This is for the fuse holder only. Fuses sold separately
