Veratron Oil Pressure Sensor 1/8"-27NPT Thread 5 Bar

Oil Pressure Sensor - 1/8"-27NPT Thread - 5 Bar

Veratron’s Pressure Sensors deliver a stable quality reading during a long lifespan. They have excellent anti-vibration performance and a wide operating temperature range.

The sensors can be used in a wide range of applications.

All sensors come with a sensor output and an insulated ground pin.

Features:

• Function - Engine oil pressure, transmission oil pressure
• Thread - 1/8"-27NPT
• Calibration - 10-184 Ohm
• Measurement Range - 5 bar
• Output Signals - Resistive
• Wide Operating Range - -25 to 120°C
• Insulated ground pin

Quick guide: https://productimageserver.com/literature/quickGuide/106078QG.pdf
